🛠️ Samsung washer error code SUD

If you have noticed a SUD code during a washing cycle, it means the suds have exceeded the usual level in the drum.  More specifically, this error means that the washing machine is reducing foaming. It has just stopped for 5-10 minutes to allow the suds to dissipate and the washing cycle to go on.

Samsung washing machine error code SUD
Samsung washer error code SUD

SUD error nature

Samsung washers have a foaming control feature. If the suds are excessive, the machine switches to the mode reducing them. The SUD error indicates the washer cannot reduce the suds, so it needs some time for the foam to dissipate naturally. It can last for quite a long time and depends on the concentration of the washing powder in the water.

All three codes – 5D, SUD, SD – are virtually the same. The SUD error is displayed in some Samsung washing machines. The other Samsung washers have different codes for the same error. The 5d and Sd error codes are equivalent to the SUD one, because the number 5 and the letter s are difficult to make out on a small display.

If you are confident it’s not about the powder, the washing machine is faulty. Namely:

  1. the foam level sensor has failed;
  2. the pressure switch is broken;
  3. the elements of the drain system (hose, branch pipe, sewer) are partially clogged;
  4. the control board has failed – an extremely rare case.

The reason for the SUD error code in the Samsung washing machine

If the display shows the SUD error, you need to find out the cause of the problem first. The error appears if:

  • You have used a washing powder not intended for automatic washing machines;
  • You have applied some concentrated powder producing excessive suds the machine cannot cope with;
  • You have used some powder of poor quality;
  • You have exceeded the required portion of the detergent for one washing cycle;
  • The foam level sensor has failed;
  • The pressure switch has been broken;
  • The release hose, branch pipe or sewer are clogged;
  • The control board has experienced a serious failure (but this reason is very rare).

First of all, consider your washing powder. You can solve the problem by changing it.

How to fix the error

If your Samsung washing machine displays the SUD code and the suds are abundant in the drum, take such action:

  1. Wait for a little for the suds to dissipate. The cycle will automatically continue afterward. Press the start button, if it is necessary for your Samsung washer;
  2. Clean the drain filter upon completing the wash cycle;
  3. Remove excess powder by running the washing machine without clothes and setting a long wash cycle and high temperature;
  4. Change the detergent if you detected an oversudsing condition constantly.

If the code is there, but no suds are in the drum:

  1. Turn off the machine;
  2. Get the clothes out; do not try to open the locked door, but drain the water through the emergency drain;
  3. Clean the drain filter;
  4. Start the machine with the previously chosen cycle to check it.

Thoroughly clean the drain and the drum from the powder residue.

If you get the SUB code during the cycle again, the foam level sensor is likely to malfunction. It is not available in every washer. Sometimes the water level sensor, which is often called the pressure switch, carries out this function instead. The foam level sensor is beyond repair, it requires replacement.

You can replace this part quite easily:

  1. turn off the water and unplug the washer;
  2. remove the top lid;
  3. find the water level sensor in the top corner of the machine;
  4. remove the air duct;
  5. disconnect the wires;
  6. install a new part;
  7. reinstall the elements in the reverse order.

In some cases, the system can show the SUD code if the suds are not gone due to some partial obstruction in the hose or the branch pipe. You need to clean these parts. Disconnect the drain hose from the machine and clean it using a cleaning wire. To clean the branch pipe take it out of the washer. You can access it through the bottom of the machine:

  1. put the washer on its side;
  2. remove the bottom carefully if there is any;
  3. loosen the pipe clamps attaching the branch pipe to the tub and the pump;
  4. wash the element and reinstall it.

When do I call a repairman?

You need a professional hand if:

  1. You are still getting the SD error code, while there are no suds in the drum. The cause may be in the malfunction of the foam level sensor. Then replace the sensor.
  2. The SUD error is displayed after starting the Samsung washing machine or during the cycle, which stops after the code has appeared. The water level sensor is out of order. Replace it.
  3. The washer is draining the water for a long time without any detergent; the error appears if you add the powder. The reason is debris clogging the branch pipe of the drain hose or sewer. To get rid of the error it is necessary to clean them.
  4. The SUD error appears when you start the washing machine or during the wash or rinse cycles. Sometimes it indicates a malfunction of the control unit. Most often, it results in unit replacement.

After the suds have dissipated, you can try to get rid of the code again. Just reset the Samsung washing machine by clicking the “Start” button.

If all the suggested measures haven’t helped to fix your washing machine, contact the repairman.
